  1. Cookin’ up a new gurdy preamp with even less noise than before. The secret ingredient? The pot itself! Turns out EM shielding is every bit as important as all those grumpy people on guitar forums spend their spare time telling each other.

  2. Turns out that it’s possible to use cheaply available (~2€ each) 7-pin SPI OLED displays with the magpie modular 8hp microbraids PCBs. A hardware and software modification are required, although as the ATMega is using software SPI it may be possible to work around the hardware modification with further software modifications.

    Please note that I would not recommend building the magpie modular micro braids module! Instead, try one of the newer adaptions (e.g. the one from Antumbra) which uses normal LED displays and have prettier panels. This guide is intended as reference for people who still have one of the old boards lying around and want to get it working without shelling out 20€ or more for a tiny OLED module.

    The seven pin SPI header on the cheap OLEDs I bought maps to the eight pin header of the original Adafruit OLED (and therefore the microbraids PCB) like this:

    CS DC RS MOSI CLK Vin GND
    |    X      X      |        \
    CS RS DC CLK MOSI Vin 3.3v GND

    I cut the relevant traces on the OLED board, scratched away some solder mask and used enamel-insulated wire to connect the traces to their new pins. Then, I installed a 7 pin female header on the braids PCB, and bridged the 3.3v and GND pins, which sounds like a terrible idea, but the board doesn’t make any use of the 3.3v pin, I’m just using it as a convenient way of connecting the OLED GND pin to the braids GND pin.

    If your OLED module has the same layout as mine, it should end up looking something like this:

    The display ends up being in a slightly different place to the original, but five minutes of filing the aluminium panel fixed that. It ended up looking a little bit messy, but the panel (from pusherman, not a magpie modular original) is extremely ugly anyway so it didn’t make much difference. I quickly cut out and filed a 3mm acrylic screen, wedged it in place and secured it with some high-viscoscity superglue.

    After reflowing and flashing both the ATMega and STM, everything was working perfectly, except the display was upside-down. Looking through the Adafruit graphics library led to a simple solution: adding the following line to the init function on line 39 of mbraidsv3.ino:

    display.setRotation(2); // Invert display for use with cheap Aliexpress 7-pin OLED

    After re-flashing the ATMega, everything worked perfectly.

    It was only after I made the hardware modification that I noticed the ATMega is using a software SPI library, with the pin definitions on lines 9-13 of mbraidsv3.ino. It should therefore be possible to achieve exactly the same result by leaving the OLED module unmodified, bridging the 3.3V and GND pins on the 8 pin OLED header on the PCB, and swapping the pin definitions around so they look like this:

    #define OLED_MOSI   10
    #define OLED_CLK   9
    #define OLED_DC    13
    #define OLED_CS    12
    #define OLED_RESET 11

    The display rotation mod will still be necessary, unless your display module is oriented differently. If anyone attempts the software modification please let me know, I’d be curious to know if it works!

  3. Useful reference for anyone trying to get a monome grid working with vanilla puredata

    Perhaps when I have developed it a bit more I will contribute a new tutorial to the monome docs website, and create a [serialosc] object for easily managing devices and connections.

  4. Today’s late-October tomato harvest, straight from the garden, no greenhouses involved. If it keeps getting colder, these will probably be some of the last.

  5. Augmented Hurdy Gurdy Experiments

    https://www.youtube.com/watch?v=hPGKeMdRU5I

    As I can’t currently commit to building a new series of gurdies due to my living situation, I’ve been keeping myself busy developing the MIDI system for my instruments, to develop new extended, augmented playing techniques.

    This video is the first demonstration of some hybrid electronic-acoustic experiments using the prototype MIDI system installed on my hurdy gurdy.

    0:22 Technique: Pitch-shifting Polyphony

    Gurdy MIDI and Audio → Apogee ONE → Macbook running a puredata patch

    Monophonic acoustic gurdy signal is pitch-shifted down in real time to play chords and harmonies. Chords and intervals on the keyboard can also be used to pitch-shift the trompette signal (0:55) or the drones. Inspired by an idea from Sébastien Tron.

    1:18 Technique: Expressive MIDI Controller

    Hurdy Gurdy MIDI → DIY Hybrid Poly Synth based off Mutable Instruments Ambika

    The keyboard and wheel sensors send MIDI note, expression and polyphonic aftertouch messages to a polyphonic synthesizer. In this case a split keyboard effect is used to play two sounds.

    1:36 Technique: Layered Acoustic and Electronic Sound

    Hurdy Gurdy Acoustic audio, Gurdy MIDI → DIY Hybrid Poly Synth based off Mutable Instruments Ambika

    1:36 The acoustic string plays a melody, the bottom half of the keyboard controls a synthesizer with a long release for subtle held chords

    2:08 Using trompette technique can send MIDI messages, used here to play synthesized percussion on an Ambika voice assigned to MIDI channel 10, whilst the keyboard plays chords.

    2:30 Acoustic trompette and melody string sound layered over subtle polyphonic synthesized chords

    Playing, Instrument and Software: Barnaby Walters https://gurdy.is https://waterpigs.co.uk
    Polyphonic Pitch-shifting idea: Sébastien Tron
    Filming, editing: Adriana Borger

  6. that Cebuano-speaking Wikipedians are vastly more thorough in cataloguing the world’s various “Goat Islands” than their English-speaking counterparts, although they neglect the more artistic uses of the phrase. Compare: https://en.wikipedia.org/wiki/Goat_Island vs https://ceb.wikipedia.org/wiki/Goat_Island

    English-speaking wikipedians would have you believe that Canada only boasts a measly two Goat Islands, but the admirable Cebuano-speaking wikipedians reveal that the true number is sixteen times greater, coming second only to the US, which clocks in at almost one hundred.

    The map of Chilean Goat Islands is possibly my new favourite wikipedia graphic:

  7. After missing the crowdfunding campaign, I was happy to finally be able to buy a copy of Tobie Miller’s excellent Bach solo hurdy gurdy CD at Chateau d’Ars last week. I couldn’t find any official album artwork on the web yet, so here is a quick scan of the cover, for anyone else who got a copy already.

  8. It is possible, if somewhat awkward, to update the Mooer Ocean Machine firmware on a mac using Wine and a cheap USB MIDI cable.

    WARNING: if the firmware update doesn’t complete successfully, it will not permanently brick your unit (as the update can always be attempted again) but the pedal will not work until a firmware is successfully installed! Attempt at your own risk, and definitely not 10 minutes before a gig.

    First, download the update from the Mooer website. The update and update software comes in a .rar archive, so you’ll need something like The Unarchiver to unpack it.

    You’ll need the latest version of Wine for Mac from winehq.org. I successfully installed the firmware update using 3.0.2. Using version 2.0 consistently failed.

    Power on the Ocean Machine in firmware update mode and plug in your USB MIDI cable as specified by the update readme. Check in Audio MIDI Setup that it’s working and recognised. Then, launch the updater using Wine. Select the firmware update file, then click “Update”. You might get a popup window helpfully saying “MIDI Device Error!!”. Try pressing Update again, if you’re lucky it will work. If not, open Terminal and try the following solution.

    The problem with (old versions of) Windows, Wine and this updater program is that they rely on the “MIDI device mapper” utility to decide which MIDI device to use. This would be fine, but under Wine for Mac there’s no easy way of seeing a list of devices or configuring which device to use.

    It is possible to change the default MIDI device used by the MIDI mapper, by creating a text file with the following code:

    REGEDIT4

    [HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\Multimedia\MIDIMap]
    "CurrentInstrument"="#1"


    #0 is the default device, so start at #1.

    I saved mine in MMap.ini. Then, run the following command:

    wine regedit MMap.ini


    and re-open the update app. If after two presses of Update you still get “MIDI Device Error!!”, then quit the updater, change #1 to #2, run wine regedit MMap.ini and try again. Repeat until successful. Yes, the update process sucks.

  9. Aitor García Rey: For a long time I felt dumb (or even betrayed!) helping people both professionally & personally and not getting love or recognition back. A few years ago I decide to change that. Now, I’ve *zero* expectations for anyone, I expect nothing. Literally. I just try to help. Period.

    @_aitor I mostly reached a similar place and it’s very relaxing. I occasionally have to remind myself that I’m helping purely because I chose to. The help might be ignored or even rejected, and that’s fine. Might have an impact on whether I chose to help that particular person in the future, though…

  10. Recently scanned some album covers I couldn’t find on the web. Here they are, to save the work for any other fans of similarly obscure music:

    Seitti, Brelo

    Tanz', Duo Haertel Wascher

    Eetu Klemetti - Kampi-Klemetin nuottikirja

    Gregory Jolivet - Alt'o solo

    Marylin Tucker & Paul Wilson - On The Tide

    Marylin Tucker & Paul Wilson and friends - Dead Maid’s Land

    The Cornwall Songwriters - The Cry of Tin

  11. Talking of [filterview] (gh), here’s the abstraction I made for it, incorporating stereo smooth filters and a nice mode switching UI made of a [hslider] hidden behind a bunch of canvases.

    Each canvas has a receive ID of $0- plus the symbol for the relevant filter mode, making the message sending for changing the colours easy.

  12. [biquad~] clicks and pops when changing coefficients, which is annoying when they’re coming from the [filterview] UI. The best way I found of smoothing them was to alternate between two biquad~ objects and crossfade between them over 3ms. This approach, while a little cludgy, is probably generalisable to a lot of similar Pd situations where smooth transitions are desirable.

  13. emma winston: For someone who complains bitterly about everything I sure am easily pleased by rain/thunderstorms

    oh man, I go wild in thunderstorms and high winds. I have yet to find somewhere with both, Iceland had great wind but no thunder, central europe is the other way round.
